R-Series

Slayer R Beadlock | Raw + Center Cap Spacer

Dunes / Desert / Moderate Rocks

starting at $449.00
/
Additional Finishes
SIZE | OFFSET | BOLT PATTERN | SKU#

  • Order Soon - Only 16 left
  • Inventory on the way
  • Free Shipping on orders of 4+ wheels*
NOTE: All Metal FX Offroad wheels require our lug nuts
Total
Recommended Products
Black Spline Drive Lug Nuts + Socket

M12x1.5 & M12x1.25 Lug nuts for UTV Wheels

$35.00

Recommended Item Image
Qty

Sold Individually
- Includes (1) Center Cap Spacer

The Kawasaki Teryx H2 uses M12x1.25 lug nuts.

The Metal FX Offroad Slayer R UTV Wheel combines our technical expertise with uncompromised attention to detail creating the ultimate in style and performance. The design of the Slayer R includes a unique concave Center and a 6061- T6 Forged Aluminum Beadlock for enhanced strength and durability.

- Solid A356 aluminum with T6 heat treatment construction
- Bolt on cap with embossed METAL FX logo for all applications
- Super strong 6061-T6 Aluminum Beadlock Ring
- Hub centric fitments for Polaris 5-Lug applications

These wheels will fit the following machines:

Polaris:
- Ranger XD 1500
- RZR Pro R
- RZR Pro S
- RZR Turbo R
- Xpedition ADV
- Xpedition XP

Segway:
- Super Villain

CF Moto:
- U10 Pro

Kawasaki:
- Teryx H2

*Before installing*

Be sure to remove the mud scrapers prior to installation of these wheels to avoid damage.
Download: Mud Scraper Removal Instructions - Here!

  • SPECIFICATIONS
SKU Model Finish Size Bolt Pattern Backspace Offset UTV/ATV Offset Bore Weight Load Lip Size Cap
78660Slayer R BeadlockGloss Black15x85x114.3 (5x4.5)4.40mm4+466.120.112602.4710326
78661Slayer R BeadlockGloss Black Contrast Cut15x85x114.3 (5x4.5)4.40mm4+466.119.412602.4710326
78662Slayer R BeadlockGunmetal Contrast Cut15x85x114.3 (5x4.5)4.40mm4+466.119.412602.4710327
78663Slayer R BeadlockRaw15x85x114.3 (5x4.5)4.40mm4+466.120.112602.4710326
78670Slayer R BeadlockGloss Black15x105x114.3 (5x4.5)5.40mm5+566.121.712603.4810326
78671Slayer R BeadlockGloss Black Contrast Cut15x105x114.3 (5x4.5)5.40mm5+566.12112603.4810326
78672Slayer R BeadlockGunmetal Contrast Cut15x105x114.3 (5x4.5)5.40mm5+566.12112603.4810327
78673Slayer R BeadlockRaw15x105x114.3 (5x4.5)5.40mm5+566.121.712603.4810326
SKU Model Finish Size Bolt Pattern Backspace Offset UTV/ATV Offset Bore Weight Load Lip Size Cap
78660Slayer R BeadlockGloss Black15x85x114.3 (5x4.5)4.40mm4+466.120.112602.4710326
78661Slayer R BeadlockGloss Black Contrast Cut15x85x114.3 (5x4.5)4.40mm4+466.119.412602.4710326
78662Slayer R BeadlockGunmetal Contrast Cut15x85x114.3 (5x4.5)4.40mm4+466.119.412602.4710327
78663Slayer R BeadlockRaw15x85x114.3 (5x4.5)4.40mm4+466.120.112602.4710326
78670Slayer R BeadlockGloss Black15x105x114.3 (5x4.5)5.40mm5+566.121.712603.4810326
78671Slayer R BeadlockGloss Black Contrast Cut15x105x114.3 (5x4.5)5.40mm5+566.12112603.4810326
78672Slayer R BeadlockGunmetal Contrast Cut15x105x114.3 (5x4.5)5.40mm5+566.12112603.4810327
78673Slayer R BeadlockRaw15x105x114.3 (5x4.5)5.40mm5+566.121.712603.4810326
