Name: 17 Outlaw R Beadlock | Raw
Brand: Riverside Warehouse
SKU: 78531
Price: 479.0 USD
Availability: InStock

best 17" outlaw r beadlock, raw at metal fx offroad

$479.00

Additional Finishes

SIZE | OFFSET | BOLT PATTERN | SKU#

17x7 | +61mm/6+1 | 5x4.5 | 78531 (Polaris 5-Lug Only)

78531

Order Soon - Only 8 left

Discontinued - Limited to In Stock Inventory

NOTE: All Metal FX Offroad wheels require our lug nuts

Total

[{"id":47156881129524,"title":"17x7 | +61mm\/6+1 | 5x4.5 | 78531 (Polaris 5-Lug Only)","option1":"17x7 | +61mm\/6+1 | 5x4.5 | 78531 (Polaris 5-Lug Only)","option2":null,"option3":null,"sku":"78531","requires_shipping":true,"taxable":true,"featured_image":{"id":30803648282676,"product_id":8666245038132,"position":1,"created_at":"2023-08-28T16:51:32-07:00","updated_at":"2023-08-28T16:51:37-07:00","alt":"best 17\" outlaw r beadlock, raw at metal fx offroad","width":3508,"height":3508,"src":"\/\/metalfxoffroad.com\/cdn\/shop\/files\/metal-fx-rogue-truck-wheel-5lug-raw-17x7.jpg?v=1693266697","variant_ids":[47156881129524]},"available":true,"name":"17 Outlaw R Beadlock | Raw - 17x7 | +61mm\/6+1 | 5x4.5 | 78531 (Polaris 5-Lug Only)","public_title":"17x7 | +61mm\/6+1 | 5x4.5 | 78531 (Polaris 5-Lug Only)","options":["17x7 | +61mm\/6+1 | 5x4.5 | 78531 (Polaris 5-Lug Only)"],"price":47900,"weight":454,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"featured_media":{"alt":"best 17\" outlaw r beadlock, raw at metal fx offroad","id":23103698042932,"position":1,"preview_image":{"aspect_ratio":1.0,"height":3508,"width":3508,"src":"\/\/metalfxoffroad.com\/cdn\/shop\/files\/metal-fx-rogue-truck-wheel-5lug-raw-17x7.jpg?v=1693266697"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

We're stoked to introduce our latest UTV cast wheel - OUTLAW! Designed to tackle any terrain with style and power at an affordable price. The Metal FX Outlaw sports a tough 10 spoke design with a durable forged 6061-t6 beadlock ring.

• Solid A356 aluminum with T6 heat treatment construction
• Bolt on cap with embossed METAL FX logo for all applications
• Hub centric fitments for Polaris 5-Lug applications

These wheels will fit the following machines:

Polaris:
- Ranger XD 1500
- RZR Pro R
- RZR Pro S
- RZR Turbo R
- Xpedition ADV
- Xpedition XP

CF Moto:
- U10 Pro

Note: The Polaris Xpedition with the HCR Kit requires at least a 0.5" spacer for clearance.

Before installing

Be sure to remove the mud scrapers prior to installation of these wheels to avoid damage.

SPECIFICATIONS

SKU	Model	Finish	Wheel Size	Bolt Pattern	Backspace (in)	Offset (mm)	Offset (in)	Center Bore	Weight (lbs)	Load Rating	Lip Size	Cap SKU	Cap Hardware SKU	BL Ring SKU	BL Hardware SKU
78513	Outlaw Beadlock	Satin Black	15x6	4x136/4x137	5	+38mm	4.5+1.5	110.2	17	1000	0.67	10311	10640	10211	10601
78514	Outlaw Beadlock	Raw	15x6	4x136/4x137	5	+38mm	4.5+1.5	110.2	17	1000	0.67	10311	10640	10214	10601
78516	Outlaw Beadlock	Satin Black	15x6	4x156	5	+38mm	4.5+1.5	132	17	1000	0.67	10311	10640	10211	10601
78517	Outlaw Beadlock	Raw	15x6	4x156	5	+38mm	4.5+1.5	132	17	1000	0.67	10311	10640	10214	10601
78519	Outlaw R Beadlock	Satin Black	15x7	5x114.3 (5x4.5)	6.3	+61mm	6+1	66.1	19	1260	0.26	10313	10640	10211	10601
78520	Outlaw R Beadlock	Raw	15x7	5x114.3 (5x4.5)	6.3	+61mm	6+1	66.1	19	1260	0.26	10313	10640	10214	10601
78530	Outlaw R Beadlock	Satin Black	17x7	5x114.3 (5x4.5)	6.3	+61mm	6+1	66.1	26	1260	0.03	10313	10640	10221	10601
78531	Outlaw R Beadlock	Raw	17x7	5x114.3 (5x4.5)	6.3	+61mm	6+1	66.1	26	1260	0.03	10313	10640	10224	10601
78532	Outlaw Beadlock	Satin Black	17x7	4x136/4x137	5	+25mm	4.5+2.5	110.2	24	1260	1.55	10311	10640	10221	10601
78533	Outlaw Beadlock	Raw	17x7	4x136/4x137	5	+25mm	4.5+2.5	110.2	24	1260	1.55	10311	10640	10224	10601
78534	Outlaw Beadlock	Satin Black	17x7	4x156	5	+25mm	4.5+2.5	132	24	1260	1.55	10311	10640	10221	10601
78535	Outlaw Beadlock	Raw	17x7	4x156	5	+25mm	4.5+2.5	132	24	1260	1.55	10311	10640	10224	10601
78538	Outlaw R Beadlock	Satin Black Contrast Cut	15x7	5x114.3 (5x4.5)	6.3	+61mm	6+1	66.1	19	1260	0.26	10313	10640	10212	10601
78539	Outlaw R Beadlock	Satin Black Contrast Cut	17x7	5x114.3 (5x4.5)	6.3	+61mm	6+1	66.1	26	1260	0.03	10313	10640	10222	10601
78548	Outlaw 6R Beadlock	Satin Black	15x7	6x139.7 (6x5.5)	6.3	+61mm	6+1	78.1	19.78	1260	0.29	10324	10640	10211	10601
78549	Outlaw 6R Beadlock	Raw	15x7	6x139.7 (6x5.5)	6.3	+61mm	6+1	78.1	19.48	1260	0.29	10324	10640	10214	10601
78550	Outlaw 6R Beadlock	Satin Black Contrast Cut	15x7	6x139.7 (6x5.5)	6.3	+61mm	6+1	78.1	19.04	1260	0.29	10324	10640	10212	10601

SKU	Model	Finish	Wheel Size	Bolt Pattern	Backspace (in)	Offset (mm)	Offset (in)	Center Bore	Weight (lbs)	Load Rating	Lip Size	Cap SKU	Cap Hardware SKU	BL Ring SKU	BL Hardware SKU
